Model – Indoor Unit: FDF71CR-S
Model – Outdoor Unit: FDC71CR-S
Super Tropical – Return Cooled Compresser: Rotary
Type of AC: Heavy Duty AC
Power Source: 1 Phase, 220 to 240V,50Hz
Maximum Cooling Capacity – Ton: 2.0
Maximum Cooling Capacity – Watts: 7620
Maximum Cooling Capacity – BTU/hr: 26000
Maximum EER/COP* 3.03
Rated Cooling Capacity – Ton: 2.0
Rated Cooling Capacity – Watts: 7108
Rated Cooling Capacity – BTU/h: 24225
Input Power**(Minimum to Maximum) -Watts : 2300 to 2507
Rated EER/COP – W/w: 2.83
Air Flow – Indoor unit – CMH: 2250
Long Reach Airflow Upto – Indoor unit – Meter: 9.14
Sound Level(H/M/L) – Indoor unit – dB: 40/34/32
Louver Swing – Indoor unit: Yes Vertical
Remote Control – Indoor unit: Controller Inbuilt on Outdoor Unit

Self Diagnosis Function – Indoor unit: Yes
Filter – Indoor unit: Anti – Backterial
Fan – Indoor unit: Super Turbo Fan
DC Fan Motor Speed – Indoor unit: Auto/High/Medium/Low/Dry
E.S.P(Pascal)# – Pa: Not Applicable
Dimension(H*W*D) – Indoor unit – mm: 1850*600*320
Dimension(H*W*D) – Outdoor unit – mm: 640*850(+65)*290
Weight – Indoor unit – Kgs : 49
Weight- Outdoor unit – Kgs : 47
Refrigerant: R410A
Refrigerant Piping – Liquide/Gas – mm: 6.35(1/4″)/15.88(5/8″)
Refrigerant Piping Lengths – Mtrs: 30 mtrs/100 feet
Refrigerant Height Difference – Mtrs: Outdoor – Higher = 10 mtrs / lower = 10 mtrss
Manpower Supply To – Out Door Unit: 2.5mm² * 3 cores(including earthing)
Connecting Wiring Between – B/w IDU & ODU:1.5mm² * 4 cores(including earthing)
Area Coverage*** – Sq Meter: 18.58 to 27.87
